Fume Hood (Air Curtain Replenishment Type) Standard 2400 x 1100/830 x 2250 mm

Features

• Energy-saving type that reduces indoor air loss by approximately 70% by directly sucking outside air from the air supply unit into the hood.
• For Acid/Alkali
• For Organic

Specification

• Specifications: Standard
• External Dimensions (mm): 2400 x 1100/830 x 2250
• Inner Dimensions (mm): 2150 x 605 x 1200
• Weight (approx. kg): 575
• Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
• Material: Exterior/Steel (Powder Coating Finish), Interior/Chemical-Resistant/Heat-Resistant Board (Flame Retardant/Phenolic Resin Laminated Board), Work Surface/Epoxy Resin Top Plate Integrally Molded Product (32 mm Thickness)
• Lifting Sash: Tempered Glass (5 mm Thickness), with Balance Weight Type Opening Limiting Key (Height 400 mm), Handle/ABS Resin
• Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
• Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
• Outlets: 2 (100 VAC 15 A with 2 connected grounding)
• lighting: LED fluorescent
• Operation Switch: Touch Panel Lighting/Fan
• safety features: exhaust airflow display
• Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
• Power connection: Terminal block with electrical box
• Air Supply Unit: Steel (Powder Coating Finish) Medium Performance Filter Built-in
• *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
• *Air supply fan and exhaust fan are not included. Please contact us.
